Specification parameterPD1008-05DPD1020-05DPowerSupplyRated input voltageDC48VDC48VOperating voltage rangeDC32-60VDC32-60Voutputrated current30Arms45Armspeak point current90Ap135Apfeedback signalhal...
| Specification parameter | PD1008-05D | PD1020-05D | |
| Power Supply | Rated input voltage | DC48V | DC48V |
| Operating voltage range | DC32-60V | DC32-60V | |
| output | rated current | 30Arms | 45Arms |
| peak point current | 90Ap | 135Ap | |
| feedback signal | hall sensor | ||
| main function | RS485 | The maximum baud rate is 115.2K, and Modbus protocol supports RTU and A SCI modes. | |
| CAN BUS | The maximum baud rate is 1M, and CAN open protocol and free protocol are supported. | ||
| defencive function | Support overcurrent, overvoltage, undervoltage, overheating, overload protection, etc. | ||
| Adapting motor type | Brushless motor | ||
| debug method | operation panel | You can set parameters, control the operation of the driver and observe the operation parameters. | |
| environment | Use field place | Indoor, free from direct sunlight, without dust, corrosive gas, flammable gas, oil mist, water vapor, dripping water or salt. | |
| altitude | The use of more than 1000 meters will be reduced by 10% for every 1000 meters increase. | ||
| ambient temperature | -10℃~+40℃ (ambient temperature is 40℃~50℃, please use it at a reduced rate) | ||
| humidity | 5%~95%RH, no water condensation. | ||
| Storage temperature | -40℃~+70℃ | ||
| structure | the protection grades | IP54 | |
| Cooling mode | Self-cooling (large current running for a long time requires auxiliary heat dissipation) | ||
| Installation mode | Horizontal installation | ||
